Intelligent Coring System

0 Reviews
3 Followers
Deployed by 1 company

Real time evaluation and selective coring

Page last modified
April 11 2024

The Intelligent Coring System (ICS) is the first core drilling technology and is a modular, fully instrumented core drilling assembly. The system features high performance electrical connections, power generation, data processing and storage, and two-way data communication to surface. The Logging While Coring (LWC) module provides essential real-time logging information of the core, including Gamma Ray, resistivity, temperature, vibrations and inner barrel stall detection. The Internal Drilling Device module allows switching between drilling and coring modes, reducing costly round trips to change the Bottom Hole Assembly.

Pros & Limitations
1
Logging while coring in real time
1
High resolution formation evaluation data on the core
1
Switch between coring and drilling mode
1
Fewer round trips to change Bottom Hole Assembly
0
Slightly reduced core diameter
Specification
Specification Title Specification Description
Areas of Application
Exploration drilling | Appraisal drilling | Coring | Logging
Capabilities
Logging While Coring, real time data transmission, selective coring and drilling.
Certifications / licences
No licenses at present.
Compliance
No particular compliance relevance.
Connectivity
Downhole data logging in real time while coring and data transmission to surface.
Measurement
Gamma ray, resistivity, inclination, temperature and vibration/ shock.
Modular design
Logging-while-coring module and optional drilling module.
Sizes
3 inch core diameter with 7.25 inch tool size for 8.375 – 9.5 inch hole size.
Temperature
150 degrees C operating and 175 degrees C survival.

Reviews

Get access to reviews

to your explorer or platform subscription to get access to the reviews written about this technology.

Technology Readiness Level

The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.

[9/9]

Development Technology demonstration Mature / Proven
Ask the supplier
 to contact this technology supplier.

CoreAll is developing the next generation core drilling solutions for the E&P industry. Although core drilling has been around for many decades, some challenges still remain, including a lack of real-time information about the subsurface, and time-consuming round trips to change the drilling equipment. CoreAll’s Intelligent Coring System addresses these challenges. With offices currently in Norway and in Houston, Texas, CoreAll is building an international presence in exploration and appraisal drilling.

Contact: +47 474 73 040
