Torrgas Gasification Technology

0 Reviews
1 Follower
2 Deploys

Sustainable, carbon negative biofuels and green chemical products from biowaste

Page last modified
February 22 2024

Our Innovative Solution: A patented two-stage gasification technology that uses torrefied biomass as the primary feedstock.

At the basis of our technology lies the use of torrefied biomass streams as a feedstock. This torrefied biomass is produced  via torrefaction, a process that transforms various heterogeneous (waste) biomass streams into a uniform, coal-like product. This torrefied biomass serves as the foundation for stable and dependable operations. Using this torrefied material, Torrgas has developed a two-stage gasification concept. It consists of a low-temperature gasifier (LTG) and a high-temperature gasifier (HTG).

The LTG produces a gas fraction rich in hydrocarbons and a solid biochar fraction. The HTG cracks the hydrocarbon-rich gas, resulting in a chemical-grade syngas that's free from tar and nitrogen. This syngas is applicable in downstream processes, such as the synthesis of DME, Hydrogen, Methanol, SAF and SNG.

By separating the biochar in the LTG, we facilitate the use of a non-slagging HTG. This results in reduced CAPEX and operational expenditure (OPEX), as well as enhanced operational dependability.

The minerals in the torrefied biomass become concentrated in the biochar. This biochar can act as an environmentally friendly fertilizer or soil enhancer, creating a closed mineral cycle. By sequestering this biochar, the process becomes carbon-negative. Alternatively, the biochar can be used as a precursor for activated carbon (useful in applications like gas purification and water treatment), blast furnace coke, composite additives, and more.

Pros & Limitations
1
Carbon-negative process due to sequestering of biochar
1
Nitrogen and Tar free syngas
1
Low CAPEX due to use of non-slagging gasifier
1
Wide range of feedstock options
1
Stable operation due to homogenous feedstock
0
Unproven at large scale
Specification
Specification Title Specification Description
2 stage reactor design
The 2 stage design allows for a non slagging gasifer that produces nitrogen and tar free syngas and biochar
Oxygen blown gasification
Production of high purity syngas
Value added by products
Biochar can be used in a variety of different sectors, such as the fertilizer, activated carbon and graphite market.
Homogeneous torrefied feedstock
Torrefied biomass usage results in a homogeneous feedstock which is much easier to handle and due to the increased energy density the transport costs are significantly lower compared to raw biomass

Reviews

Get access to reviews

to your explorer or platform subscription to get access to the reviews written about this technology.

Technology Readiness Level

[7/9]

Development Technology demonstration Mature / Proven
Ask the supplier
 to contact this technology supplier.

At Torrgas our purpose is to provide industrial customers with a solution to make fully circular biofuels and green chemical products, with a negative carbon footprint. We aim to play a significant role in the global transition from fossil to renewable products.

As a technology company, we innovate for society with the belief that we can substitute fossil resources by renewable alternatives.

We consider the whole value chain from sourcing to final product.

We sell our proprietary gasification technology under license, initiate and develop projects with our knowledge on biomass resourcing to final products.
