Supercritical CO2 Flushing System (SCCO2)

0 Reviews
0 Followers

Cleans long pipelines while maintaining turbulent flow

Page last modified
November 21 2024

Ensure optimal operational efficiency and minimise downtime with the innovative Supercritical CO2 Flushing System (SCCO2).

This advanced cleaning technology delivers unparalleled cleanliness for control lines and umbilicals, even over extended distances exceeding 20km. The SCCO2 system offers significant advantages over traditional methods:

  • Superior Cleanliness Levels: Achieve exceptional cleanliness exceeding AS4059 Class 3/ISO 4407 12/9 standards, demonstrably reducing the risk of blockages and subsequent equipment failures.
  • Unmatched Long-Distance Performance: The low viscosity of supercritical CO2 guarantees turbulent flow throughout the entire cleaning process, regardless of line length. This eliminates the limitations inherent in conventional flushing systems.
  • Minimised Downtime: Experience significantly lower pressure drops compared to traditional systems. Our SCCO2 system delivers a pressure drop of less than 3,000 PSI over a ¼” OD 13,000-metre control line, demonstrably reducing cleaning time and associated production delays.
  • Environmentally Friendly Operation: The SCCO2 system utilises CO2, a readily available, non-toxic resource. This eliminates the need for harsh chemicals, resulting in a reduced environmental impact.

The SCCO2 system provides a complete, self-contained solution for your cleaning requirements:

  • High-Pressure Cleaning: Operates at pressures up to 550 bar with a maximum CO2 flow rate of 120 kg/hr, ensuring effective cleaning.
  • Exceptional Filtration: Dual-stage filtration (7 and 2 microns) guarantees exceptional cleanliness.
  • User-Friendly Control System: Provides intuitive control via a PLC with a 24-inch touchscreen interface.
  • Portable and Deployable: Packaged in a convenient 20-foot transportable enclosure for easy deployment on-site.
  • CE Certified: Certified for operation within the European Economic Area.

Invest in the SCCO2 Flushing System for demonstrably improved operational efficiency, reduced downtime, and enhanced environmental responsibility.

Contact us today to discuss your specific requirements.

Pros & Limitations
1
Can obtain a good inflow test on leaking chemical injections check routes
1
Dissolves Wax and Grease
1
Can clean for long distances, while maintaining turbulent flow
1
Cleans to a AS4059 Class 3 (ISO 4407 12/9)
1
Extremely Environmental Friendly
1
Can remove blockages
1
Small environmental footprint
1
Cost effective vs workover
Specification
Specification Title Specification Description
ID
9000-456
Max working pressure
550 bar
Max flow CO2
120kg/h (400kg/h)
Design temperature
1200C/-200C
Approvals
CE marked in accordance with EC/2006/42; Machinery Directive, Directive 97/23/EC, can come in a 2.7 -1 Container on request

Reviews

Get access to reviews

to your explorer or platform subscription to get access to the reviews written about this technology.

Technology Readiness Level

The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.

[9/9]

Development Technology demonstration Mature / Proven
Ask the supplier
 to contact this technology supplier.

IKM Testing UK is an ISO-certified UK-registered company that provides various oil, gas, petrochemical, and energy industry services. The company has facilities in Cramlington and Westhill/Aberdeen and offers services such as pipeline pre-commissioning, umbilical testing, topside services, equipment rental, personnel provision, upstream services, valve services, methane emissions quantification, training services, and 3D technical animation. IKM Testing UK is part of the larger IKM Group and has obtained quality, environmental, and safety certifications.
