Remotely monitored autonomous crane operations

Page last modified
February 22 2024

Since late 2017, Aker BP and Optilift has collaborated on developing technology for remotely monitored autonomous offshore crane operations. The development has been performed in stages, maturing the technology readiness level (TRL) where among other a model crane, simulator and an electric lattice boom offshore crane from has been used to test and demonstrate the technology.

The autonomous crane control system from Optilift is supporting Aker BP’s mechanical AutoHook concept, and is set up to be able to perform lifts of cargo without the need for human interaction. After successful demonstrations of the technology using the model crane in 2019, full-size crane testing and further maturation of the technology was performed onshore during 2021 and thereafter offshore during 2022.

After the lattice boom crane was installed offshore at the Valhall field of Aker BP, testing and optimization of the Optilift solution continued throughout 2022. The tests started with gradually increasing complexity on the loading decks on the rig, to confirm the assistance systems and autonomy, before moving onto tests in calm weather conditions on a supply vessel.

The technology can be retrofitted to existing cranes, or integrated by the OEM with new cranes. Optilift provides sensors and software technology that allows safe remote-controlled crane- and lifting operations, which can be further extended to autonomous lifting and logistics handling.

By remote controlling crane- and lifting operations, it is possible to allow one crane operator handle multiple cranes at different sites. This means reduced travel costs, increased safety, and efficiency. In times where it may be difficult to source qualified personnel, or travel restrictions are enforced, crane operations may still take place without delays.

Pros & Limitations
1
Operate the crane from a remote location
1
One person operates multiple cranes
1
Enables unmanned installations
1
Enables loading cargo onto normally unmanned installations before personnel arrives for maintenance campaigns
1
Allows uninterrupted lifting operations despite travel restrictions
1
Existing cranes in the field can be upgraded to be remote controlled
1
Enabler for autonomous lifting operations
0
Network connectivity is required to the crane
Specification
Specification Title Specification Description
Areas of Application
Cranes located on- and offshore, in ports, harbors, on vessels, wind-mills etc..
Cargo handling
AutoHook concept enables personnel-free decks.
Usability
Safe and intuitive remote control by the use of Optilift Assistance Systems.
Safe operating
Auto lift-off, auto landing, anti-pendulum and anti-collision Assistance Systems ensure safe operation even in case of network connectivity issues and human errors.
Motion compensation
Auto Landing, Auto Lift-Off, Relative Heave Compensation, Anti-Pendulum and AutoHook control ensures controlled and partly automated complex lifts.
Versatility
Integrates with Digital Logistics solution to automate planning and tracking of lifting plans and cargo locations.

Reviews

Get access to reviews

to your explorer or platform subscription to get access to the reviews written about this technology.

Technology Readiness Level

The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.

[6/9]

Development Technology demonstration Mature / Proven
Ask the supplier
 to contact this technology supplier.

Safer and more efficient cargo handling - reduce CO2 emissions, cut costs and improve safety.

Optilift offers products for digitalized, remote controlled and autonomous cargo handling. With innovative software and unique AI technology, we contribute to a safer and more efficient work environment.
