Expandable - Wireline Deployed Casing Patch

Page last modified
June 30 2024

Wireline deployed straddle utilizing our expandable technology allowing for isolation of wellbore issues whilst providing a maximized post installation ID. The optimised post expansion ID enables continued wellbore access, future intervention, optimizes production rates & maximizes well lifecycle.



Key Features

  • Shoeless design (no drill out of shoe required post install)
  • High expansion capabilities
  • Stackable design with metal to metal sealing, allowing multiple patches to be stacked
  • Recessed seals whilst RIH to optimize RIH OD
  • Available in carbon steel or CRA materials and with gas tight sealing capabilities
  • Deployable on E-line & Coil tubing
  • Expandable technology allows for far larger post installation ID's than conventional methods

Common Applications

  • Isolation of tubular leaks
  • Isolation of unwanted water, gas & sand ingress
  • Corrosion isolation
  • SSSV remediation
  • Isolation of leaking/compromised completions components
Pros & Limitations
1
One-trip system, with no shoe drill out required
1
Larger post installation ID than conventional straddle systems
1
Stackable with metal to metal seals to create longer straddles to suit specific applications
1
Available in standard carbon steel or application specific CRA materials
1
Configurable with smart completion products such as AICDs to provide comprehensive workover solutions
0
When deploying on E-Line, only one straddle joint can be deployed per trip (~40ft). If patching a long section, multiple trips would be required with this system to stack straddles
Specification
Title Description
Theme/Discipline
Well OperationsProduction TechnologyIntegrity
Length
Up to ~40ft deployable in one trip
Stackable
For longer sections, patches can be deployed consecutively and stacked to create a longer patch with metal to metal seals
Deployment Method
E-Line or Coil

Reviews

Get access to reviews

to get access to the reviews written about this technology.

Technology Readiness Level

The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.

[9/9]

Development Technology demonstration Mature / Proven
Ask the supplier
 to contact this technology supplier.

Coretrax is a global leader in oil and gas well integrity and production optimisation. Operating throughout the world, our team takes an integrated and boundary pushing approach to improve production performance and deliver well intervention efficiencies.

With a portfolio of over 50 technologies, Coretrax is focused on innovation and delivering the highest standards of service delivery, available 24-7. Acting as a trusted partner to operators and collaborating with other service companies, we work hard to unlock additional value.
