Motion Amplification Technology
Non contact vibration visualisation tool developed by RDI Technologies
Page last modified
April 11 2024
Motion Amplification (MA), a unique revolutionary technology in terms of vibration verification, troubleshooting, Research & Development and root cause analysis via its amazing ability to clearly visualise vibration motion.
MA is simple to use, quick and easily helps you identify where the vibration motion is coming from, by visualising a complete system, asset, machine or components motion using the cameras 2.3 million sensors. You can even get accurate frequency, time waveform and amplitude data from anywhere on the MA video using the non-contact software module.
Pros & Limitations
1
Reduces time solving vibration problems over using Vibration Analysis alone, takes 1 min to collect and process motion video in the field | Often leading to quick root cause analysis
1
Negates the need for costly and time consuming ODS studies | Cheap, simple and quick to deploy and get valuable results
1
Visualise vibration issues rather than just looking at graphs, actually see the problem and how the machine is really operating. Great communication tool
1
Excels on machine base problems and pipework
1
Non-contact accurate vibration measurements possible from anywhere on the image using its 2.3 million pixel sensors
0
Needs additional lighting (indoor) for higher frequency problem visualisation
Specification
| Title | Description |
|---|---|
| Theme/Discipline | Rotating EngineeringIntegrityInspection |
| Core Tech | Instrumentation & Measurement |
|
Acquisition System
|
I7 processor,16GB RAM 500GB SSD, dual batteries and MIL-STD-810G.
|
|
Areas of Application
|
Rotating equipment, pipework, vessels and structures.
|
|
ATEX certified
|
Non ATEX
|
|
Case
|
Watertight, dustproof and crushproof.
|
|
Compliance
|
CE
|
|
Frequency
|
IRIS M 0-650Hz with reduced resolution | IRIS MX 0-700Hz full HD | 10,000 Hz with reduced resolution
|
|
Lenses
|
6mm, 12mm, 25mm, 50mm and 100mm.
|
|
Motion compensation
|
Vibration pads: 95% impulse absorption.
|
|
Sample rate
|
IRIS M up to 1300 fps | IRIS MX up to 20,000 fps | 1400 fps full HD
|
|
Tripod
|
Professional Grade with Pistol Grip.
|
Reviews
Technology Readiness Level
The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.
[9/9]
Development
Technology demonstration
Mature / Proven
