Methanol analysis: Fast, accurate, portable analysis of produced fluids
OMMICA is a low cost alternative to GC for methanol detection on crude oil, condensate, water, and gas
Page last modified
April 11 2024
The OMMICA MeOH analysis consists of a simple, highly accurate, portable colourimetric test to determine methanol in crude oil and water.
Accuracy is gained by addition of accurately measured reagents to a sample. This is then reacted at a specific time and temperature, to control the reaction and the resultant colour gives the level of methanol.
Absorbance of the reacted sample colour is measured using a colourimeter to give an accuracy of +/- 1ppm.
The analysis has been developed to be as accurate as gas chromatography, but allow on-site testing to take place in the field or offshore, through use of portable equipment.
Pros & Limitations
1
Significant cost savings on traditional analysis methods
1
Designed to be easy for non-specialist users to use well
1
As accurate as Gas Chromatography
1
Designed to be used on- and off-shore
1
Water extraction of oil not required before analysis of oil samples
0
OMMICA is not an ASTM method, however it correlates well with the standard ASTM method using GC
0
The OMMICA method may require a couple of hours training for optimum results (can be provided).
Specification
| Specification Title | Specification Description |
|---|---|
|
Areas of application
|
FPSO, custody transfer, oil storage tanks, pipeline monitoring, restart after well shut-down
|
|
Accuracy
|
+/- 2 ppm
|
|
Range (standard)
|
1 to 750 ppm (oil), 20 to 1500 ppm (water)
|
|
Range (extended)
|
Up to 10% (oil), up to 80% (water)
|
|
Detection threshold
|
< 1 ppm in oil, < 10 ppm in water, < 10 ppm in gas
|
|
Efficiency
|
Up to 100 samples/day possible
|
|
Cost reduction
|
Low set-up cost compared with GC. Low ongoing OPEX
|
|
Deployment
|
Can be effectively used by non-specialists
|
|
Training
|
Dedicated YouTube training videos channel, summary videos on website, in-person training can be provided if required
|
|
Quality
|
3rd party testing confirms equivalence with ASTM method (GC) (Major analytical contractor)
|
|
Operational impact
|
No need to wait for samples to be helicoptered back onshore to a lab, and for a third party to analyse samples, before decisions can be made
|
|
Versatility
|
Suitable for use on or offshore. Only requires 1 m2 (or less) of working space. Robust equipment.
|
