HTX Digital
Predictability at your fingertips
Page last modified
March 14 2023
HTX Digital is a proactive digital heat exchanger management service focused on improving heat exchanger efficiency and reducing carbon emissions. This is achieved by remotely monitoring heat exchangers using existing sensor data. Glacier Energy's subject matter experts provided key insights into the failure modes of heat exchangers over a long period and developed tools to analyse and identify these failures early leading to optimal performance and reduced maintenance burden.
The calculations in the tool are based on industry standards by Tema and ASME and look at key failure mechanisms:
- Tube Vibration
- Tube Expansion
- Fouling
- Velocity Limits
- Cyclic loading
- Energy Efficiency
- Pressure and Temperature limits
By understanding the condition of your equipment, we can help reduce Opex savings by up to 30% due to smart cleaning and maintenance. We can help reduce carbon footprint through the same mechanisms and by understanding the potential failure mechanisms we can help with planning repairs at the optimal time for operations.
Pro/con
Uses existing sensor data
Uses existing PI/Historian data
Can be applied to multiple heat exchanger types, Shell and Tube, Air Cooled, Plate and Frame, Printed Circuit.
Specific calculations have been developed for each exchanger type
Identifies hidden failures in heat exchangers
Where sensor data is unavailable we can work with clients to provide calculated values
Fully supported service
We can identify optimal cleaning cycle for heat exchangers
We can report on production losses as a result of fouling
We can report on excess CO2 production as a result of fouling
We have the flexibility to work with clients to develop new calculations as required
We have the flexibility to work with clients to add sensors if required
Limited at present to existing sensors that are present
Limited to sites with Historian data at present
Specification
Velocity Limits
Calculations to measure Tube side velocity limits, Tema impingement limits and shear stress in shell and tube exchangers
Vibration Limits
Calculations to measure Fluid Elastic Instability, Turbulent Buffeting, and Vortex Shedding in shell and tube exchangers plus accoustic resonance in Air Cooled Exchangers
Opex cost
Calculations to measure fouling and energy efficiency as a result of fouling. Optimisation of cleaning can reduce Opex costs by 30%
Carbon Footprint
Calculated value of additional CO2 produced as a result of fouling
Relative Business Impact
Technology Readiness Level
[8/9]
Development
Technology demonstration
Mature / Proven
