High Velocity Thermal Spray (HVTS®)

0 Comments
0 Followers

Asset Integrity in Process Vessels

Page last modified
July 14 2025

Proven in Oil & Gas, Petrochemical, and Refining Industries Worldwide

Reliable Corrosion Protection

  • 10–15+ year lifespan in aggressive process environments
  • 30–50% cost savings vs. weld overlay or component replacement
  • Fast application rates for large surface areas (3-6m2/shift/machine)
  • Maintains wall thickness and asset integrity
  • No need for PWHT or curing time. Back in service immediately.
  • Predictable performance even in high-H₂S, chlorides, or CO₂ atmospheres
Pros & Limitations
1
Near-zero porosity (<0.5%) & Excellent bond strength (>83 MPa)
1
Can be applied over existing weld overlays & Low heat input with no thermal distortion
1
Fast application rates for large surface areas (3-6m2/shift/machine)
1
No need for PWHT or curing time. Back in service immediately.
1
Lasting protection for 15+ years. Can be spot repaired, no need for complete reapplication
0
Specialized equipment, material and process required.
Specification
Title Description
Theme/Discipline
IntegrityInspectionBlasting & CoatingCorrosion ManagementRepair
Core Tech
Paint/Coating
Areas of Application
Process vessels, Amine Vessels, Caustic Vessels, Knockout Drums, Crude Desalters, Separators and Scrubbers, Reactor Vessels, Columns and Towers, Process Pre-heaters, Steam generators, Condensers, Sulfur Recovery Units (SRUs)
Typical Coating Thickness
500μm to 1mm
Bond Type
Micro-mechanical interlocking (MMI) (>35 MPa)
Corrosion Resistance
Excellent
Erosion Resistance
Excellent
Application Speed
(3-6m2/shift/machine) 3x faster than machined WOL
PWHT Requirement
No
HAZ Formation
No
Base Material Distortion
No
Temperature Resistance
>500°C/932°F
Steam-Out Resistance
Yes
Typical Service Life
15+ years
Technology Readiness Level

The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.

[9/9]

Development Technology demonstration Mature / Proven
Ask the supplier
 to contact this technology supplier.

Headquartered in Virginia, Integrated Global Services, Inc. (IGS) is an international provider of on-site surface protection solutions. With over 35 years of experience helping customers solve metal wastage, reliability, and energy efficiency problems in mission-critical equipment, IGS is an industry leader in the development and application of solutions in challenging operating environments. Learn more at https://integratedglobal.com/ or follow us on LinkedIn, X, YouTube, or Facebook.

Country of Headquarters
United States
Contact: +1 (888) 506 2669
