Maximize the value of biogas by efficiently converting it to liquefied biomethane and liquid biogenic CO2

Page last modified

September 20 2023

Nordsol offers bio-LNG production installations and expert services. Our innovative technology makes small-scale bio-LNG production from biogas sustainable, easy to operate, and economically attractive.

Energy efficiency and low emissions are of critical importance for the sustainable and economically viable production of bio-LNG from raw biogas. Nordsol has largely reinvented the production process by creating an optimal balance between energy efficiency and process control complexity, taking advantage of the unique characteristics of biogas. The result is a compact, highly integrated system of raw biogas treatment and liquefaction, combined with carbon capture and liquefaction.

Pro/con

Significantly increases the value of biogas

Energy efficient technology, low carbon intensity

Integrated biogenic CO2 liquefaction

Reliable, easy to control production process. Unmanned.

Proven technology

Compact installation, low equipment count

Independent from gas grid limitations

Permit required

Specification

Plant capacities Plant capacities range from biogas flows of 500 Nm3/hour (5 tons bio-LNG per day) to 6000 Nm3/hour (60 tons bio-LNG per day)

Energy consumption Total energy (electrical power) needed for upgrading raw biogas and liquefaction to bio-LNG is 1.3 kWh/kg bio-LNG. No heat demand, no consumables needed,

Plant sizes Depending on requirements and capacity plant size ranges from 750 m2 to 2500 m2
