Automa Smart Solution - G4C - PRO - Advanced Remote Monitoring for Cathodic Protection
Cutting-Edge Solutions for Corrosion Prevention
Page last modified
April 23 2025
AUTOMA provides one of the most advanced and reliable solutions for remote monitoring of cathodic protection, operating in over 40 countries since 1987.
Smart GOLIAH (G4C-PRO)
The G4C-PRO data logger is a remote monitoring device with particularly small dimensions which allow it to be directly housed in standard pole containers, such as the Conchiglia, M28 post and other typical posts..The G4C-PRO series features 5 galvanically isolated channels with a selectable range of ±500mV to ±100V, ultra-high precision (±0.02%), and simultaneous DC/AC measurement. It includes a solid-state switch for instant-off potential measurements (ErFree) with 1ms switching speed, crucial for stray current environments. Each device records one measurement per second, collecting up to 86,400 data points per day.
With an optional SNODE accessory, G4C-PRO can remotely control select T/R models via RS485 and WebProCat software, allowing real-time adjustments. Firmware updates ensure continuous optimization.
Key Features:
- Instant Off & Polarization Current Measurement: Essential for accurate cathodic protection assessment, minimizing IR error.
- Daily Reports & Remote Access: Data sent via LTE/4G or satellite, including min, max, avg, mode, standard deviation, and alarms.
- 24-Hour On-Demand Data Upload: LTE units can provide detailed logs for anomaly investigation.
Additional Solutions:
- Smart ER-PROBE (G4C-PRO-ERP): Measures corrosion rate using standard ER Probes.
- Smart IJ (G4C-PRO-JOINT): Monitors insulated joint efficiency, detecting dielectric bypasses with remote control capability.
- Smart Permanent Reference Electrode (PRE): Patented solution with automatic temperature compensation, internal diagnostics, and offset calibration for accurate potential readings.
Automa's innovative technology ensures precise, real-time monitoring, optimizing cathodic protection management worldwide.
Pros & Limitations
1
Enhanced Monitoring and Control
1
High-Frequency Data Collection
1
Long Battery Life and Alternative Power Sources
1
Comprehensive Data Analysis and Reporting
1
Versatile Communication Options
1
Increased Safety and Efficiency
1
Customizable Alarms and Smart Diagnostics
1
Scalable and Compatible with Various Installations
1
Wide Range of Data Representation with Different Graph Options
1
Mobile App for Device Field Installation and Maintenance
0
The devices need to be physically set up and installed
Specification
| Title | Description |
|---|---|
| Theme/Discipline | PipelinesIntegrity(Proactive) MonitoringCorrosion Management |
| Core Tech | Instrumentation & Measurement |
|
Primary Use Case
|
Full-scale remote monitoring for pipelines and complex installations
|
|
Measurement Channels
|
5 galvanically isolated channels for AC/DC measurements on each channel simultaneously.
|
|
Power Supply
|
Internal Battery (Min. 4 years) and external power supplies (solar/mains) with internal rechargeable backup battery.
|
|
Data Management
|
365-day storage, daily reports with 86400 samples, WebProCat (Scada by Automa) integration, configuration with any Scada system.
|
|
Measures per Second on Request
|
Frequency measurement per second on all channels. Storage of the daily log of 86,400 samples in a cyclic queue for a duration of 7 to 62 days, depending on the enabled channels, and possibility of full transmission on demand.
|
|
Real Time Alarms
|
User-configurable alarm thresholds for each channel and for external power supply failure; possibility of alarm notification (SMS/EMAIL) in real time
|
|
Communication
|
Local: Bluetooth;
Remote: GSM/LTE/Ethernet; integration with WebProcat and Scada Internal or external antenna |
|
Installation
|
DIN rail, Conchiglia, M28, custom
|
|
Ease of Installation and Maintenance
|
Fido Universal is the mobile app developed by Automa that provides device field installation and maintenance assistance. It allows complete control of devices in the field, improving installation performance and maintenance tasks.
|
|
Durability
|
IP68 -20C to +85C
|
|
Compliance with Standards
|
ISO 15589-1, ISO 22426, ISO 18086, ISO 21857, EN 12954, EN 13509, UNI 11094, UNI 10950, APCE guidelines, NACE SP0169, TM0497, RP0104
|
|
Dimensions
|
L 12.9 x H 8.5 x P 7.7 cm
|
|
Weight
|
0.8 kg.
|
Technology Readiness Level
The Technology Readiness Level (TRL) indicates the maturity level of novel technologies. Learn more about the TRL scale used by us.
[9/9]
Development
Technology demonstration
Mature / Proven
Automa is an Italian company founded in 1987 that designs, engineers, and manufactures Made in Italy technologies for remote monitoring in the Oil, Gas, and Water sectors, as well as Building Automation solutions for the civil sector. The company, led by CEO Giorgio Giorgetti, has developed extensive expertise in electronic technologies and innovation over the years, positioning itself as a leader in both national and international markets. Automa operates under two main brands: GOLIAH for remote monitoring solutions in industrial sectors, and XEFIRO for Building Automation systems. The company is committed to continuous technological innovation, developing smart, flexible, and reliable solutions that aim to facilitate and support their customers' work. With a strong emphasis on Made in Italy quality and a global presence in numerous countries, Automa prides itself on sharing best practices and providing high-performance, long-term solutions tailored to meet evolving market needs.
